خزان الأسمنت جديد POLYGONMACH 1000 tONNES BOLTED TYPE CEMENT SILO

SILO CAPACITY 1.000 TONS

SILO HEIGHT 20840 mm

SILO DIAMETER Ø 8250 mm

QUANTITY OF SILO LEGS 8

SILO OUTPUT DIAMETER Ø 300 mm

NUMBER OF COMPONENTS 191

SILO WEIGHT 72000 kg(With Legs:75 000kgs)

MATERIAL OF SILO LEGS Ø273 x 10 mm STEEL PIPE

SUPPORTS OF SILO LEG 100 mm C CHANNEL

SHEET METALS OF SILO LEG 25-30 mm

CONICAL PART SUPPORT MATERIAL 160 mm STEEL C CHANNEL

CONICAL PART MATERIAL S235JR, 10 mm SHEET METAL

SILO BODY MATERIAL S235JR, 8 - 6 - 5 mm SHEET METAL

SILO TOP COVER MATERIAL S235JR, 5 mm SHEET METAL

CHARGING PIPE 4" STEEL PIPE UP TO SILO LEG

INNER MANHOLE IS PRESENT

OUTER MAN HOLE IS PRESENT

SILO ROOF INCLUDES HANDRAILS

MAINTENANCE PLATFORM IS PRESENT

STRUCTURAL ANALYSIS IS MADE FOR THE SILOS AND MANUFACTURING PROCESS DEPENDS ON APPROVED PROJECTS.
